The ASM 03068036 is a master optical artifact designed for the Automatic Camera Tools (ACT) software suite. This plate provides the machine's vision processors with a "Perfect Geometric Grid" to calculate and eliminate optical distortions such as lens parallax, sensor tilt, and chromatic aberration. By placing the 03068036 within the machine's field of view, the system can self-correct the spatial relationship between the gantry position and the camera's center point. This process is the foundation of "Zero-Drift Placement," ensuring that the machine maintains its $\pm 22\mu m$ accuracy even as environmental temperatures or lighting conditions fluctuate.
GEEKVALUE provides the 03068036 with a focus on Pattern Contrast and Edge Definition. We recognize that vision algorithms are only as accurate as the edges they detect; our plates feature Micro-Lithographed Patterns that offer the highest possible grayscale contrast for SIPLACE digital vision systems.
Technical Specifications
Feature | Technical Data |
Product Type | Master Optical Calibration Standard |
Part Number (P/N) | 03068036 |
Function | Camera-to-Camera & Gantry-to-Vision Calibration |
Pattern Geometry | Multi-Dot / Grid Matrix for Distortion Correction |
Substrate Material | Ultra-Low Expansion Optical Grade Composite |
Surface Treatment | Anti-Reflective (AR) Matte Coating |
Compatibility | SIPLACE X, SX, TX Series Vision Platforms |
Strategic Performance Advantages
· Achromatic Reference Accuracy: The 03038036 is designed to be Wavelength Neutral. Whether your machine uses Blue, Red, or White LED lighting for vision, the patterns on this plate maintain identical contrast and edge profiles, preventing "Color-Shift Errors" in the calibration logic.
· Dimensional Stability Control: GEEKVALUE’s 03068036 is constructed from a Thermally Insensitive Substrate. Unlike standard PCBs used for "DIY" calibration, this plate does not expand or contract with factory temperature swings, providing a constant "True North" for your machine's coordinate system.
· High-Resolution Fiducial Grids: The plate contains Multi-Scale Calibration Marks. This allows it to calibrate both the high-magnification "Fine-Pitch" cameras and the wide-field "Large Component" cameras within the same ACT routine, ensuring consistent accuracy across all head types.
· Parallax-Free Surface Planarity: The plate is precision-lapped to be Optically Flat. This ensures that the focus distance (Z-height) is identical across the entire surface of the plate, allowing the ACT software to accurately map the camera’s focal plane and eliminate "Fisheye" distortions at the edges of the image.
The GEEKVALUE Advantage: "Vision Integrity, Mechanical Truth"
1. 360° Total Cost Optimization (TCO)
A machine with uncalibrated vision will have higher "Vision Reject" rates and "False Pick" alarms. GEEKVALUE optimizes your TCO by providing 03068036 Calibration Plates that are Certified for Pattern Integrity. By ensuring your vision system is perfectly mapped, we help you reduce component waste and maximize the effective throughput of your SIPLACE line.
2. Trusted by 400+ Public Companies
Global leaders in high-density server manufacturing and automotive LiDAR assembly trust GEEKVALUE for their vision standards. Our 03068036 plates are the standard choice for listed companies that require "Optical Traceability" to meet the stringent quality audits of the Tier-1 electronics industry.
3. Optimized for "TX-Series" Dual-Vision Logic
GEEKVALUE’s 03068036 is factory-verified to support the "Synchronized Vision" features of the TX and X-series machines. We ensure the plate's fiducials are optimized for the latest CMOS sensor architectures, allowing for a faster and more reliable ACT calibration cycle.
Frequently Asked Questions (FAQ)
Q1: How often should I use the 03068036 ACT Calibration Plate?
GEEKVALUE recommends a Vision System Check every month, or whenever the machine reports a "Vision Calibration Timeout" or an "Alignment Drift" error. It is also mandatory after any camera replacement or gantry motor service.
Q2: Can I use a high-quality print-out instead of the 03068036 plate?
NO. Standard printing lacks the sub-micron edge definition and thermal stability required for SIPLACE vision systems. Using anything other than a precision-lithographed plate like the 03068036 will introduce "Phantom Errors" into your machine's coordinate system, leading to placement defects.
Q3: How should I clean the 03068036 plate if it gets dusty?
The surface is sensitive. Use only Non-Abrasive Optical Wipes and high-purity Isopropyl Alcohol (IPA). Never touch the pattern area with bare fingers, as skin oils can create "Haloing" that confuses the vision software during calibration.
Q4: Is this plate compatible with older SIPLACE HF or D-series machines?
The 03068036 is specifically designed for the ACT (Automatic Camera Tools) software found on X, SX, and TX series. Older machines use a different calibration target geometry. Always check your software version before selecting a calibration plate.
