The ASMPT 03070280 (2057) is a specialized placement nozzle engineered to bridge the gap between high-speed passive placement and larger IC handling. While smaller nozzles in the 20xx series focus on lightweight acceleration, the 2057 is designed for Mechanical Grip Strength. It features an expanded internal vacuum orifice that allows for a larger volume of airflow, creating a robust suction "seal" on components that might have textured surfaces or slightly off-center mass distributions.
GEEKVALUE provides the 03070280 with a focus on Dynamic Balance. We understand that when a CP20 head rotates at high speeds with a slightly larger component, any axial deviation in the nozzle can lead to "Centrifugal Displacement." Our 2057 nozzles are verified for Precision Concentricity, ensuring that the component remains locked in position regardless of gantry acceleration.
Technical Specifications
Feature | Technical Data |
Product Type | High-Torque / High-Flow SMT Nozzle |
Part Number (P/N) | 03070280 |
Nozzle Series | 2057 |
Compatible Head | SIPLACE CP20 (PowerHead) |
Tip Construction | Hardened Composite with Matte Finish |
Application Range | Large Passives, Small BGA, SOT, and Specialized SMDs |
Identification | Integrated Mechanical Recognition Interface |
Strategic Performance Advantages
· High-Volume Airflow Channel: The 2057 nozzle incorporates a wider internal bore. This allows the vacuum system to compensate for minor air leaks that occur when picking up components with matte or semi-porous surfaces, ensuring the component doesn't drop during high-speed transit.
· Anti-Wobble Tip Geometry: The tip of the 03070280 is engineered with a Reinforced Support Profile. This design provides a larger contact area, which acts as a "stabilizer" for taller components, preventing them from leaning or tilting during the placement stroke.
· Vision-Optimized Silhouette: To ensure the SIPLACE vision system can clearly distinguish the component's leads, the 2057 body is finished with a specialized non-reflective coating. This creates a high-contrast background that eliminates "Edge-Bleed" in vision processing, leading to higher placement accuracy.
· Thermal-Stable Composite Shaft: Industrial SMT environments can fluctuate in temperature. The 03070280 is built with materials that have a low coefficient of thermal expansion, ensuring that the nozzle dimensions and vacuum seal remain consistent from the first board of the morning to the last board at night.
The GEEKVALUE Advantage: "Stability in Complexity"
1. 360° Total Cost Optimization (TCO)
Large-format and odd-form components are often high-value items. GEEKVALUE optimizes your TCO by providing 03070280 Nozzles that have undergone Vacuum Seal Integrity Audits. By reducing "Mid-Air Drops," we protect your most expensive components and eliminate the hidden costs of line stoppages and manual rework.
2. Trusted by 400+ Public Companies
Global leaders in automotive infotainment and smart home control systems trust GEEKVALUE for their specialized nozzle needs. Our 2057 nozzles are the standard choice for listed companies that require "Reliable Versatility" when handling diverse component portfolios on a single production line.
3. Optimized for Long-Run Durability
GEEKVALUE’s 03070280 nozzles are inspected for Tip-to-Bore Alignment. We ensure that the mechanical interface with the CP20 head is airtight and robust, allowing for millions of reliable cycles even when handling heavier components that place more stress on the nozzle shaft.
Frequently Asked Questions (FAQ)
Q1: Is the 2057 nozzle compatible with the SIPLACE TX series?
Yes. The 03070280 is fully compatible with the CP20 head (PowerHead) used across the TX, SX, and X platforms.
Q2: Can I use this nozzle for standard 0603 or 0805 components?
While it can pick them up, the 2057 is specifically optimized for larger or heavier parts. For standard passives, GEEKVALUE recommends the 2034 or 2037 series to maintain the highest CPH (Components Per Hour).
Q3: How do I maintain the high-flow vacuum channel?
Because the 2057 has a wider bore, it can be more prone to collecting airborne flux residue. GEEKVALUE recommends an ultrasonic cleaning cycle every 100,000 cycles to maintain optimal airflow.
Q4: Is the tip material ESD-safe?
Absolutely. All GEEKVALUE ASMPT nozzles are treated with a dissipative coating to ensure static charges are safely moved through the machine’s grounding system.
Q5: What is the packaging standard for 2057 nozzles?
Each 03070280 is housed in an Individual ESD-Safe Protective Capsule. This ensures the vacuum orifice and the identification shaft are protected from contamination and physical damage during transit.
