The ASM 00141398 is a high-performance intelligent feeder specifically optimized for 88mm wide carrier tapes. Positioned as a critical module for complex SMT assemblies, this feeder is designed to handle wide-body ICs, multi-pin connectors, and specialized RF shielding frames. The standout feature of the 00141398 is its Integrated Optical Sensor System, which acts as a real-time monitor for tape indexing accuracy. By constantly verifying the sprocket hole alignment, the sensor allows the feeder to compensate for the "Tape Stretch" often found in 88mm plastic carriers, ensuring that heavy components are presented to the placement head with absolute positional integrity.
GEEKVALUE provides the P/N 00141398 with a focus on Deceleration Smoothness. We recognize that 88mm components often have sensitive internal structures; our feeders are verified for "Soft-Stop" logic, preventing the inertial jarring that can cause component displacement or internal micro-cracks during the feeding cycle.
Technical Specifications
Feature | Technical Data |
Product Type | Wide-Format Intelligent Feeder with Position Sensor |
Part Number (P/N) | 00141398 |
Tape Width | 88mm |
Compatibility | SIPLACE X, SX, and D-Series Gantry Systems |
Indexing Drive | Digital Micro-Stepping Motor with Closed-Loop Sensor |
Peeling Control | Intelligent Tension-Sensing Take-up System |
Interface | ASM Gold-Plated X-Feeder Intelligent Bus |
Strategic Performance Advantages
· Active Indexing Correction: The 00141398 does not rely on "blind" stepping. Its internal sensor detects the exact edge of the tape pocket, allowing the controller to make micro-adjustments on-the-fly. This is critical for 88mm tapes, where even a 0.1mm deviation over a wide area can lead to a "Vision Alignment Failure."
· Optimized Peeling Torque Logic: Wide cover tapes (88mm) require a specialized peeling angle and consistent force. The 00141398 utilizes an intelligent take-up motor that adjusts its torque based on the resistance of the cover tape adhesive, ensuring a smooth, vibration-free opening of the component pocket.
· Reduced Component "Pop-Out" Risk: Large components in wide pockets are susceptible to air-pressure changes and vibration. The 00141398’s drive profile is engineered to eliminate the "snapping" motion during start-up, ensuring that the component remains perfectly flat and seated against the bottom of the pocket.
· Seamless SIPLACE OS Integration: As a fully digital "Sensor Feeder," the 00141398 provides the machine with detailed telemetry. It reports not only the component count but also the mechanical health of the feeding cycle, enabling proactive maintenance before the feeder exceeds its precision tolerances.
The GEEKVALUE Advantage: "Wide-Format Precision"
1. 360° Total Cost Optimization (TCO)
The components carried in 88mm tapes are typically high-value assets. GEEKVALUE optimizes your TCO by providing 00141398 Sensor-Feeders that have undergone Lateral Drift Audits. By ensuring a 100% pick-up success rate, we help you eliminate the hidden costs of component scrap and the line-stoppages associated with manual "No-Pick" troubleshooting.
2. Trusted by 400+ Public Companies
Global leaders in aerospace, server hardware, and automotive telematics trust GEEKVALUE for their wide-format feeder requirements. Our 00141398 feeders are the standard for listed companies that require "Zero-Defect" supply chains for their most complex high-density boards.
3. Enhanced Data Traceability
In an Industry 4.0 environment, the 00141398 acts as an intelligent node. GEEKVALUE’s units ensure that the unique feeder-ID and material batch data are perfectly synchronized with your MES, providing the end-to-end traceability required for high-reliability electronics manufacturing.
Frequently Asked Questions (FAQ)
Q1: How many slots on a standard SIPLACE trolley does the 00141398 occupy?
A: Given its 88mm width, the 00141398 is a multi-slot feeder. It typically occupies the space equivalent to 11 standard 8mm slots. GEEKVALUE can assist in optimizing your trolley layout to accommodate these larger units efficiently.
Q2: Is the sensor system sensitive to dust or solder paste debris?
A: The 00141398 features a shielded optical path, but like all precision instruments, it performs best in a clean environment. GEEKVALUE recommends regular cleaning of the sensor window as part of your standard preventive maintenance.
Q3: How does GEEKVALUE verify the accuracy of the 88mm indexing?
A: Every unit undergoes a Dynamic Optical Alignment Test. We use high-resolution cameras to verify that the feeder stops within $\pm 0.02\text{mm}$ of the target coordinate over a continuous 8-hour stress run.
Q4: Can this feeder be used for both plastic and metal carrier tapes?
A: Yes, the sensor logic and drive torque are designed to handle the friction profiles of standard 88mm embossed plastic and specialized metal carrier tapes used for heavy shielding components.
Q5: What is the packaging standard for this precision sensor module?
A: We use Class-0 ESD and Reinforced Custom Crating. Each 00141398 is vacuum-sealed in anti-static shielding and housed in a multi-layered foam container to ensure the delicate sensors and high-torque motors are fully protected during transit.
