The ASM 00141498 is a specialized intelligent feeder engineered for the most challenging miniaturized components in the SMT industry. Designed for 4mm carrier tapes—the standard for ultra-small passives and semi-conductor dies—this feeder is the critical enabler for high-density smartphone, wearable, and SiP (System-in-Package) assembly. The 00141498 features a high-frequency optical sensor that provides sub-micron feedback to the drive controller. This closed-loop system is essential for 4mm tapes, where the mechanical tolerance of the tape itself can often exceed the component size; the sensor ensures each pocket is perfectly centered under the nozzle, regardless of tape stretch or environmental factors.
GEEKVALUE provides the P/N 00141498 with a focus on Micro-Placement Integrity. We recognize that with 4mm tapes, there is no room for error; our feeders are verified for "Steady-State Indexing" to eliminate the micro-vibrations that cause 01005 components to shift or flip.
Technical Specifications
Feature | Technical Data |
Product Type | 4mm Intelligent Sensor Feeder (Ultra-Fine Pitch) |
Part Number (P/N) | 00141498 |
Tape Width | 4mm |
Compatibility | SIPLACE X, SX, and D-Series Platforms |
Sensor Type | High-Speed Closed-Loop Position Tracker |
Component Range | 01005 (Metric 0402) and Specialized Micro-SMDs |
Interface | Gold-Plated ASM 12-Pin Intelligent Bus |
Strategic Performance Advantages
· Sub-Micron Step Resolution: The 00141498 utilizes a specialized micro-stepping motor paired with sensor feedback to achieve indexing accuracy that exceeds standard 8mm feeders. This precision is vital for 4mm tapes where the component pockets are spaced with extreme density.
· Active Vibration Dampening: For micro-components, the inertia of a standard "Start-Stop" cycle can be disruptive. The 00141498 features a programmed "Soft-Acceleration" curve, ensuring the 4mm tape advances with a smooth, fluid motion that keeps the component perfectly flush against the pocket base.
· Ultra-Thin Tape Handling: 4mm carrier tapes are often thinner and more delicate than larger formats. This feeder’s tape path is precision-polished to reduce friction, preventing tape buckling or sprocket-hole wear that can lead to feeding inconsistencies in high-speed runs.
· ESD-Safe Micro-Path: Given that 01005 components are highly susceptible to static cling, the 00141498 features a fully conductive material path and integrated grounding points. This ensures the component remains "neutral" and releases easily from the pocket during high-speed vacuum pick-up.
The GEEKVALUE Advantage: "Precision at the Edge"
1. 360° Total Cost Optimization (TCO)
In micro-component placement, "No-Pick" events aren't just a nuisance—they are a major source of vacuum nozzle wear and machine derating. GEEKVALUE optimizes your TCO by providing 00141498 Sensor-Feeders that have undergone Micro-Coordinate Validation. By delivering a nearly 100% pick-up rate for 01005 components, we directly increase your line's net throughput.
2. Trusted by 400+ Public Companies
Global leaders in advanced semiconductor packaging and high-end mobile device manufacturing trust GEEKVALUE for their 4mm feeding solutions. Our 00141498 feeders are the industry benchmark for listed companies that require "Zero-Failure" performance in ultra-high-density assembly environments.
3. Optimized for Digital Traceability
The 00141498 integrates seamlessly with ASM’s intelligent kitting software. GEEKVALUE’s units ensure that every reel change is logged and every pick-up is verified by the internal sensor, providing the granular data needed for full traceability in regulated industries like medical and automotive electronics.
Frequently Asked Questions (FAQ)
Q1: Why is the sensor so critical for 4mm tapes compared to 8mm?
A: At the 4mm scale, the ratio of component size to tape tolerance is very high. The sensor in the 00141498 detects the physical sprocket holes to correct for any minute tape inconsistencies, which is the only way to ensure reliable pick-up for metric 0402 (01005) components.
Q2: Can this feeder be used on any SIPLACE X-Series trolley?
A: Yes, it is physically compatible with standard X-series interfaces. However, due to the high-resolution requirements, please ensure your machine software version is updated to support the specialized 4mm feeding profiles.
Q3: How does GEEKVALUE test the accuracy of a 4mm feeder?
A: Every unit is subjected to a 24-Hour Continuous Micro-Indexing Test. We use high-magnification optical inspection to verify that the center of the 4mm pocket remains within a $\pm 0.01\text{mm}$ window throughout the entire run.
Q4: Is the 00141498 compatible with "Gold" or "Silver" performance tiers?
A: The 00141498 is an intelligent sensor-integrated unit that meets and often exceeds standard "Gold" performance metrics for the 4mm format, specifically focused on precision rather than just raw speed.
Q5: What is the packaging standard for such a delicate instrument?
A: We use Class-0 ESD and Precision-Fitted Shielding. Each 00141498 is vacuum-sealed and housed in a multi-layered, shock-absorbent foam container to ensure the micro-stepping motors and optical sensors arrive in perfect factory-spec calibration.
